Sampling valve designed for high temperature and high pressure
Metallic piston type
DN15 sampling valve for high temperature and high pressure service
TA LUFT up to 300°C TUV SUD certified
ISO 15848 Fugitive emission TUV SUD certified
API 607 Fire safe TUV SUD certified.
Triple stem seals (double FFKM and adjustable graphite packing)
Threaded or flanged connexion
115G
DN 15 (½”)
+300°C / +572°F
-20°C / -4°F
PN10
Vacuum to 10 bar (0-145 psi)
Ra ≤0.8 µm (polishing on request)
Ra ≤3.2 µm (polishing on request)
Bottle 150 ml*, glass Borosilicate with stainless steel protection (*autre sur demande)
½ NPT 8, Other on request
